Business Desktops
Productivity-Enhancing
Select your HORIZON Desktop
HORIZON D12160
HORIZON T12160
| Micro-ATX FF | 1 SOCKET | 64 Go RAM | 4 SATA | 1 Gb Ethernet | 10 USB |
- Small Form Factor or Mini Tower
- Intel® 12th, 13th or 14th gen. Core™ processor
- Up to 64 GB of DDR4 3200 MT/s
- 4 SATA 6 Gb/s ports and 2 M.2 slots
- 1 PCIe 4.0 x16 and 1 PCIe 3.0 x1 slots
- 2 USB 3.2 gen 1 ports, 2 USB 3.1 gen 1 ports and 6 USB 2.0 ports
- VGA, DisplayPort 1.4 and HDMI 2.1 ports
- 8-channel High Definition audio controller
- CIARA HORIZON D12160 / T12160 datasheet
- CIARA HORIZON D12160 / T12160 User Guide
- CIARA HORIZON D12160 / T12160 Disassembly Guide
- CIARA B777-4 casing datasheet
- CIARA Y777-3 casing datasheet
- CIARA Y777-1 casing datasheet
- CIARA Y777-8 casing datasheet
- CIARA S777-1 casing datasheet
- CIARA S777-8 casing datasheet
HORIZON D12170
HORIZON T12170
| Micro-ATX FF | 1 SOCKET | 64 GB RAM | 4 SATA | 1 Gb Ethernet | 12 USB |
- Small Form Factor or Mini Tower
- Intel® 12th, 13th or 14th gen. Core™ processor
- Up to 64 GB of DDR4 3200 MT/s
- 4 SATA 6 Gb/s ports and 1 M.2 slot
- 1 PCIe 4.0 x16, 2 PCIe 3.0 x1 and 1 PCI slots
- 2 USB 3.2 gen. 2, 2 USB 3.2 gen.1 and 8 USB 2.0 ports
- 2 DisplayPort 1.4 and VGA ports
- 8-channel High Definition audio controller
- CIARA HORIZON D12170 / T12170 Datasheet
- CIARA HORIZON D12170 / T12170 User Guide
- CIARA HORIZON D12170 / T12170 Disassembly Guide
- CIARA B777-4 casing datasheet
- CIARA Y777-3 casing datasheet
- CIARA Y777-1 casing datasheet
- CIARA Y777-8 casing datasheet
- CIARA S777-1 casing datasheet
- CIARA S777-8 casing datasheet
HORIZON D12750
HORIZON T12750
| Micro-ATX FF | 1 SOCKET | 128 GB RAM | 4 SATA4 | 1 Gb Ethernet | 13 USB |
- Small Form Factor or Mini Tower
- Intel® 12th, 13th or 14th gen. Core™ processor
- Up to 128 GB of DDR5 5600 MT/s
- 6 SATA 6 Gb/s ports and 2 M.2 slots
- 1 PCIe 4.0/3.0 x16 and 2 PCIe 3.0 x1 slots
- 4 USB 10 Gb/s ; 1 USB 5 Gb/s type C ; 2 USB 5 Gb/s ports ; 6 USB 2.0 ports
- HDMI 2.1 and 2 DisplayPort 1.4 ports
- 8-channel High Definition audio controller
- CIARA HORIZON D12750 / T12750 datasheet
- CIARA HORIZON D12750 / T12750 User Guide
- CIARA HORIZON D12750 / T12750 disassembly guide
- CIARA B777-4 casing datasheet
- CIARA Y777-3 casing datasheet
- CIARA Y777-1 casing datasheet
- CIARA Y777-8 casing datasheet
- CIARA S777-1 casing datasheet
- CIARA S777-8 casing datasheet
- CIARA C666-4 casing datsheet
- SSD PCIe® Gen 4.0 x4 NVMe™ M.2 datasheet
HORIZON D12760
HORIZON T12760
| Micro-ATX FF | 1 SOCKET | 192 GB RAM | 8 SATA | 2 x 2.5 Gb 1 x 1 Gb Ethernet | 13 USB |
- Small Form Factor or Mini Tower
- Intel® 12th, 13th or 14th gen. Core™ processor
- Up to 192 GB of DDR5 5600 MT/s
- 8 SATA 6 Gb/s ports and 2 M.2 slots
- 1 PCIe 5.0 x16 slot, 1 PCIe 4.0 x4 slot and 1PCIe 3.0 x1 slot
- 1 USB 3.2 Gen 2 ports Type-C®, 1 USB 3.2 Gen 2 ports Type-A,
- 4 USB 3.2 Gen 1 ports Type-A, 1 USB 3.2 Gen 1 port Type-C,
- 2 USB 3.2 Gen 1 ports, 4 USB 2.0 ports
- HDMI 2.1, DisplayPort 1.4 and VGA ports
- 8-channel High Definition audio controller
HORIZON D12770
HORIZON T12770
| Micro-ATX FF | 1 SOCKET | 128 GB RAM | 4 SATA | 1 Gb Ethernet | 15 USB |
- Small Form Factor or Mini Tower
- AMD Ryzen™ 7000 or 8000 Series processor
- Up to 128 GB of DDR5
- 4 SATA 6 Gb/s ports and 2 M.2 slots
- 1 PCIe 4.0 x16 slot, 1 PCIe 4.0 x4 slot and 1PCIe 4.0 x1 slot
- 1 USB 3.2 Gen 2 ports Type-C®, 3 USB 3.2 Gen 2 ports Type-A,
- 2 USB 3.2 Gen 1 ports Type-A, 1 USB 3.2 Gen 1 port Type-C,
- 8 USB 2.0 ports
- HDMI 2.1 and 2 DisplayPort 1.4 ports
- 8-channel High Definition audio controller
HORIZON T12780
| ATX FF | 1 SOCKET | 256 GB RAM | 2 SATA | 2.5 Gb Ethernet | 14 USB |
- Mini Tower
- AMD Ryzen™ 7000, 8000 or 9000 Series processor
- Up to 256 GB of DDR5
- 2 SATA 6 Gb/s ports and 4 M.2 slots
- 1 PCIe 5.0 x16 slot, 1 PCIe 4.0 x8/x4 slot and 1PCIe 4.0 x1 slot
- 2 USB 4 (DP) ports
- 2 USB 3.2 Gen 2 ports Type-C®, 1 USB 3.2 Gen 2 ports Type-A
- 5 USB 3.2 Gen 1 ports Type-A
- 4 USB 2.0 ports
- 1 HDMI 2.1 and 2 USB 4 (DP) ports
- 8-channel High Definition audio controller
HORIZON D13560
HORIZON T13560
| Micro-ATX FF | 1 SOCKET | 128 GB RAM | 4 SATA | 1 Gb Ethernet | 11 USB |
- Small Form Factor or Mini Tower
- Intel® 12th, 13th or 14th gen. Core™ processor
- Up to 128 GB of DDR5 5600 MT/s
- 4 SATA 6 Gb/s ports and 2 M.2 slots
- 1 PCIe 3.0/4.0 x16 and 2 PCIe 3.0 x1 slots
- 4 USB 3.2 gen. 1 ports ; 1 USB type C port ; 6 USB 2.0 ports
- HDMI 2.1, 2 DisplayPort 1.4 and 1 VGA ports
- 8-channel High Definition audio controller
- CIARA HORIZON D13560 / T13560 datasheet
- CIARA HORIZON D13560 / T13560 user guide
- CIARA HORIZON D13560 / T13560 disassembly guide
- CIARA B777-4 casing datasheet
- CIARA Y777-3 casing datasheet
- CIARA Y777-1 casing datasheet
- CIARA Y777-8 casing datasheet
- CIARA S777-1 casing datasheet
- CIARA S777-8 casing datasheet
HORIZON D15160
HORIZON T15160
| Micro-ATX FF | 1 SOCKET | 128 GB RAM | 4 SATA | 1 Gb Ethernet | 10 USB |
- Small Form Factor or Mini Tower
- 15th Generation Intel® Core™ Ultra (Series 2) processor
- Up to 128 GB of DDR5 6400 MT/s
- 4 SATA 6 Gb/s ports and 2 M.2 slots
- 1 PCIe 4.0 x16 slot and 1 PCIe 4.0 x1 slot
- 1 USB 5 Gb/s type C, 2 USB 10 Gb/s type A, 1 USB 5 Gb/s type A and 6 USB 2.0
- HDMI 2.1 and DisplayPort 1.4
- 8-channel High Definition audio controller
- ENERGY STAR® 9.0 qualified
HORIZON D15170
HORIZON T15170
| Micro-ATX FF | 1 SOCKET | 128 GB RAM | 4 SATA | 1 Gb Ethernet | 12 USB |
- Small Form Factor or Mini Tower
- 15th Generation Intel® Core™ Ultra (Series 2) processor
- Up to 128 GB of DDR5 6400 MT/s
- 4 SATA 6 Gb/s ports and 1 M.2 slot
- 1 PCIe 5.0 x16 slot, 1 PCI2 4.0 x16 (x1 mode) slot and 1 PCIe 4.0 x1 slot
- 2 USB 10 Gb/s type A, 1 USB 5 Gb/s type A, 1 USB 5 Gb/s type C and 8 USB 2.0
- 1 HDMI 2.1 and 2 DisplayPort
- 8-channel High Definition audio controller
- ENERGY STAR® 9.0 qualified
HORIZON D15750
HORIZON T15750
| Micro-ATX FF | 1 SOCKET | 256 GB RAM | 4 SATA | 1 Gb Ethernet | 12 USB |
- Small Form Factor or Mini Tower
- 15th Generation Intel® Core™ Ultra (Series 2) processor
- Up to 256 GB of DDR5 6400 MT/s
- 4 SATA 6 Gb/s ports and 2 M.2 slots
- 1 PCIe 5.0 x16 slot, 1 PCIe 4.0 x16 (mode x4) and 1 PCIe 4.0 x1 slot
- 2 USB 10 Gb/s type C, 2 USB 10 Gb/s type A, USB 5 Gb/s type A and 6 USB 2.0
- HDMI 2.1 and 2 DisplayPort 1.4
- 8-channel High Definition audio controller
- ENERGY STAR® 9.0 qualified
HORIZON T15760
| ATX FF | 1 SOCKET | Upmto 256 GB RAM | 4 + 2 SATA4 | 2 x 2.5 Gb Ethernet | 16 USB |
- Mid-Tower
- 15th Generation Intel® Core™ Ultra (Series 2) processor
- Up to 256 GB of DDR5 9066 MT/s
- 4 SATA 6 Gb/s ports, 1 SlimSAS port and 4 M.2 slots
- 2 PCIe 5.0 x16 slots (x16 or x8/x8) and 1 PCIe 4.0 x16 slot (x4)
- 1 Thunderbolt™ 4 USB Type-C® port, 2 USB 20 Gb/s Type-C® port
- 6 USB 10 Gb/s Type-A ports, 3 USB 5 Gb/s type A ports and 4 USB 2.0 ports
- 1 HDMI™ port, 1 Intel® Thunderbolt™ 4 port (USB Type-C®) support DisplayPort and Thunderbolt™ video outputs, and 1 VGA port from AST2600
- 8-channel High Definition audio controller
- ENERGY STAR® 9.0 qualified
HORIZON D15770
HORIZON T15770
| Micro-ATX FF | 1 SOCKET | 256 GB RAM | 4 SATA | 2.5 Gb Ethernet | 15 USB |
- Small Form Factor or Mini Tower
- AMD Ryzen™ 7000 or 8000 Series processor
- Up to 256 GB of DDR5
- 4 SATA 6 Gb/s ports and 3 M.2 slots
- 1 PCIe 5.0/4.0 x16 slot (supports x16/x8/x4 mode)
- 1 PCIe 4.0 x16 slot (supports x4 mode)
- 2 USB 10 Gb/s ports Type-A,
- 1 USB 5 Gb/s port Type-C, 4 USB 5 Gb/s type A,
- 8 USB 2.0 ports
- HDMI 2.1 and 2 DisplayPort 1.4 ports
- 8-channel High Definition audio controller
- ENERGY STAR® 9.0 qualified
Warranty: CIARA’s limited hardware warranty includes a one year, parts and labour with return to CIARA USA or Canada. Customers may purchase an extended warranty of up to 5 years on parts and labour with different support levels. Please contact CIARA at 1-877-242-7272 for complete warranty details including limitations and transferability.
Spare Parts: All devices include spare parts availability for a minimum of three (3) years after the date of sale, or as per the minimum warranty of the device, with optional coverage extended up to five (5) years.
